Thin film evaporator is a kind of high-efficiency evaporation and distillation equipment that uses a scraper system to force liquid into a film for evaporation or distillation. It can also perform unit operations such as deodorization, defoaming reaction, heating, cooling, etc. It can be widely used in Chinese and Western pharmaceutical, food, light work, petroleum, chemical, environmental protection and other industries. The system can also be used in the process of recovering organic solvents from industrial waste liquids.
Thin film evaporator Features:
1. The scraper system is made of PTFE and SS316L stainless steel, which is extremely corrosion-resistant;
2. The maximum temperature of the system can reach 200℃, and the maximum temperature of the jacket can reach 300℃;
3. The scraper system forces the liquid into a thin film by rotation, which improves evaporation efficiency and reduces operation time;
4. The high-precision glass tube enables the liquid to form a complete integrated film on the heating surface;
5. The main body of the evaporation is made of high borosilicate glass, which can well observe the operation process of the entire process;
6. All parts in contact with liquid and gas are made of PTFE or high borosilicate glass, which is extremely corrosion-resistant;
7. According to customer requirements, the specifications can be ?60--?300.
Thin film evaporator Technical Parameters
| Specifications | Effective evaporation area ㎡ | External condensation area ㎡ | Barrel diameter(mm) | Feeding funnel volume | Handling traffic | Motor Power W | Maximum speed RPM/MIN |
| L/H | |||||||
| BF-60 | 0.05 | 0.2 | 60 | 0.25L | 0.8 | 120 | 600 |
| BF-75 | 0.1 | 0.25 | 75 | 1L | 1.5 | 120 | 600 |
| BF-100 | 0.15 | 0.3 | 100 | 1L | 3 | 120 | 600 |
| BF-150 | 0.25 | 0.4 | 150 | 2L | 5 | 120 | 600 |
| BF-200 | 0.4 | 0.5 | 200 | 3L | 8 | 120 | 600 |
| BF-300 | 0.6 | 0.8 | 300 | 5L | 10 | 200 | 300 |
