Bag filter side entry stainless steel filter introduce
Overall height : 39 inch
Outer Diameter : 8 inch
Fully comply with GMP requirement, professionally mechanical polishing and electrolytic polishing
Internal polish to be Ra< 0.6 um, external polish to be Ra< 0.8 um
Maximum operating pressure 90 psi
Housing material available in stainless 304 and 316L
O-ring available in EPDM, PTFE, Viton, and Silicone
Suitable for filtration of beer, syrup, fruit juice, and juice concentrate etc
Applicable for food & beverage, pharmaceutical, chemical and electronic filtration
Bag filter side entry stainless steel filter features:
| Model |
filter-bag |
cylinder diameter mm |
Filter bag size |
volume of flow T/H |
pressure MPA |
accuracy degree um |
thickness mm |
square measure m2 |
in out style |
| BF1D-4S | #4 single bag | 114 | 105*380 | 10 | 0-0.6 | 1-200 | 2 | 0.15 | 1-inch quick fit |
| BF1D-1S | #1 single bag | 204 | 180*430 | 18 | 0-1.0 | 1-200 | 2.5 | 0.25 | DN40 flange |
| BF1D-2S | #2 single bag | 204 | 180*810 | 36 | 0-1.0 | 1-200 | 2.5 | 0.5 | DN50 flange |
